Escorts Powertrac 445 Plus Tractor

PARAMETERS

SPECIFICATION

ENGINE

Power (HP)

47 hp

No of cyl & cubic capacity (cc)

3 Cyl,2761 CC

Rated

2000

TRANSMISSION

GEAR BOX

8Forward + 2Reverse

LOCATION OF GEAR BOX SHIFTING

Center Shift / side shift option

Rear Axle

Inboard Reduction

CLUTCH

Clutch

Single Clutch / Dual optional

ROAD SPEEDS

Speed Forward (kmph)

2.7-32.5

Speed Reveseve (kmph)

3.2-10.8

Maximum speed (kmph)

36

PTO

PTO

Single 540

540 PTO AT ENGINE RPM

Single at 1800

STEERING

Steering

Balanced Power Steering /
Mechanical Single drop arm option

Hydraulic lift capacity (kg)

SENSI-1 -1600kg

BRAKES

Brakes

Multi Plate Oil Immersed Disc Brake / Multi Plate Dry Disc Brake optional

TYRES

Front tyre

6.0 x 16 / 6.5 X 16

Rear Tyre

13.6X28 / 14.9 X 28

FRONT AXLE

Front Axle

Fixed-Straight Axle

WEIGHTS & DIMENIONS

Total Weight, kg

1980

Wheelbase (mm)

2060

Overall Length (mm)

3540

Overall Width (mm)

1750

Ground Clearance (mm)

425

Fuel tank

Capacity (ltrs)

50
