Product Description
Specifications of Escort Steeltrac 15 and 18 Farm Tractor: | ||||
| TRACTOR MODEL NAME | STEELTRAC-15 | STEELTRAC-18 | ||
| ENGINE | ||||
| HP Category | 15 | 18 | ||
| Number of cylinders | 1 | 1 | ||
| Capacity as specified by applicant (CC) | 611 | 895 | ||
| Fly Up Engine RPM | 3350 to 3500 | 2700±100 | ||
| Low idling RPM | 1100 to 1300 | 900-1200 | ||
| Maximum torque @ Erpm | 1400 to 1500 | 1400 to 1500 | ||
| Rated Engine RPM | 3000 | 2300 | ||
| TRANSMISSION SYSTEM | ||||
| Clutch | ||||
| Type | Single, Dry Friction plate | Single, Dry Friction plate | ||
| Gearbox | ||||
| Type | Sliding cum Synchromesh | Sliding cum Synchromesh | ||
| Number of speeds | 10 (8+2) | 10 (8+2) | ||
| - Forward | 8 | 8 | ||
| - Reverse | 2 | 2 | ||
| Location of main gear & Range gear shifting levers | Centre Shifting, In front of Operator’s seat | Centre Shifting, In front of Operator’s seat | ||
| Nominal Speed Range (KM/h) | 1.6 to 24.5 (With 8x18 Tyre Size) | 1.70 to 27.04 (With 8x18 Tyre Size) | ||
| 1.80 to 28.73 (With 8.3x20 Tyre Size) | ||||
| Maximum Speeds @ Fly up (KM/h) | 27.5 (With 8x18 Tyre Size) | 30.50 (With 8x18 Tyre Size) | ||
| 32.50 (With 8.3x20 Tyre Size) | ||||
| Steering | ||||
| Type of steering | Mechanical | Mechanical | ||
| POWER TAKE OFF | ||||
| Type | Multy speed PTO | Multy speed PTO | ||
| BRAKE SYSTEM | ||||
| Type | Mechanical, Dry Friction Disc Brake | Mechanical, Dry Friction Disc Brake | ||
| HYDRAULIC SYSTEM | ||||
| Hydraulic Lift capacity at Horizontal Position (Kgs) | 450 | 450 | ||
| Transport Lock | Yes | Yes | ||
| Auxiliary Valve | ||||
| CAPACITIES | ||||
| Fuel tank (Ltrs) | 17.8 | 17.8 | ||
| Total lub. oil of engine (Ltrs) | 2.1 | 2.65 | ||
| Gearbox common with Diff. & Hydraulic | 19 ltr | 19 ltr | ||
| Steering (Ltrs) | 0.45 | 0.45 | ||
| TRACTOR Total Weight (Kgs) | 815.00 | 925 | ||
| TYRE SIZE | ||||
| Front | 5.20x14 | 5.20x14 | ||
| Rear | 8x18 | 8x18 Std. 8.3X20 Opt. | ||
| Others Features | ||||
| Draw bar | Yes | Yes | ||
| Recovery Bottle | NA | NA | ||
| Fuel Cap | ||||
| Type of Driver Seat | Adjustable | Adjustable | ||
| New Fender Rail | ||||
| Neutral Safety Switch | NA | NA | ||
| Mobile Charger | NA | NA | ||
| Toe Hook Mtg bracket | Yes | Yes | ||
| Toe Hook | Yes | Yes | ||
