Escorts Farmtrac Champion 35 Tractor
Product Details:
Escorts Farmtrac Champion 35 Tractor Price And Quantity
- 1 , , Unit
Escorts Farmtrac Champion 35 Tractor Trade Information
- Others
- All India
Product Description
Specifications of Escorts Farmtrac Champion 35 Tractor:
| PARAMETERS | SPECIFICATIONS |
| ENGINE |
|
| No of Cylinders | 3 |
| Power at Rated ERPM (HP) | 35 |
| Rated ERPM | 2200 |
| TRANSMISSION |
|
| Gear Box Type | 8F+2R Full Constant Mesh |
| Location of Gear Shifting | Center Shift |
| Rear Axle Type | Straight Axle |
| CLUTCH |
|
| Type | Single Clutch |
| ROAD SPEEDS## |
|
| Forward Road Speed @ Rated ERPM | 2.6-29.8 Kmph |
| Reverse @ Rated ERPM | 3.0-10.6 Kmph |
| BRAKES |
|
| Type | Multi Plate Oil Immersed Brakes |
| HYDRAULICS |
|
| Type & Lift Capacity [Horizontal position] | ADDC - 1500 kg |
| Spool Valve | Quick release coupler |
| STEERING |
|
| Type | Mechanical - Single Drop Arm/Balanced Power Steering |
| POWER TAKE OFF |
|
| PTO Type | Single 540 |
| 540 PTO at Engine RPM | 1810 |
| TYRE SIZES |
|
| Front | 6.0 X 16 |
| Rear | 12.4 X 28 |
| FRONT AXLE |
|
| Type | Fixed Axle |
| FUEL TANK CAPACITY |
|
| Litres | 50 |
| WEIGHT & DIMENSIONS |
|
| Total Weight, kg | 1895(Unballasted) |
| Wheelbase (mm) | 2100 |
| Turning Radius (mm) | 3000 |
| Overall Length (mm) | 3315 |
| Overall Width (mm) | 1710 |
| Ground Clearance (mm) | 377 |
